Product details
Application Scenarios:
Performance halls、sports venues、professional shows、auditoriums、multifunctional halls、conference systems
Functional Features:
96k 24BIT sampling rate
15-channel PEQ input, 10-channel PEQ output, high-pass and low-pass filters
All-pass filter
Supports dynamic equalizer
Configurable Dante network digital audio input and output
USB plug-and-play automatic connection software, supports RS232 central control, supports TCP/IP wired and wireless control
Supports mobile app wireless control
Supports networking and commissioning of multiple devices, remote monitoring
Product technical specifications
Specifications | 4-in 8-out digital audio processor（New） Optional Dante network digital audio input | Background noise | 20Hz-20kHz，A-wt,-93dBu |
Audio system delay | 2.8ms | THD+N | -90dB(@0dBu,1kHz,A-wt)/Line |
Digital model conversion | 24-bit | Signal-to-noise ratio | 110dB(@16dBu,1kHz,A-wt)/Line |
Sampling rate | 96kHz | USB | Micro-B type, Driver-free |
Input channel | 4-way balanced input，line level | RS232 | Serial port communication |
Audio interface | Canon lens male and female ends | TCP/IP Network port | RJ-45 |
Input impedance | 22kΩ | Indicator light | CLIP，LEVEL，EDIT，MUTE |
Maximum input level | 20dBu/Line | Power supply range | AC90V---264V 50/60 Hz |
Output channel | 8-way balanced output, line level | Dimensions (L*W*H) | 483*265*44.5 mm |
Output impedance | 150Ω | Net weight | 3.2KG |
Frequency response curve | 20Hz-40kHz(±0.5dB)/Line | Operating temperature | -20℃~-60℃ |
