Product details
Passive two-way frequency design;
Two low-frequency units are arranged in a V-shape mirroring the high-frequency horn on either side, creating a symmetrical design relative to
the high-frequency unit, enhancing sound directionality;
High frequencies are transmitted through a 1.4-inch compression horn, which diffuses at a horizontal angle of 30°；
The vertical 90° dispersion surface allows for precise projection, effectively reducing environmental sound interference.
Product technical specifications
Frequency response | 50Hz -20kHz(-10dB) | Input Connection | 2x Neutrik NLT4M（+1/-1） |
Nominal Directivity HxV（-6 dB) | 30°×90° | Dimension(mm) | H/W/D（680/328/385）mm |
Nominal Sensitivity ity（1W/1m） | 97dB | Weight | 28KG |
Maximum Peak SPL | 125dB/131dB（Peak） | Case Material | First grade multi-layer plywood |
Power Handing(AES/Peak) | LF：600W（Rated）/2400W（Peak） HF：110W（Rated）/440W（Peak） | Surface Treatment | PCP |
Driver Components | LF：2×10”Driver HF：1×3”Driver | Protection rating | IP54 |
Nominal lmpedance | 8Ω |
