Product details
The box is made of custom European-grade multilayer plywood, with a surface coated in PCP (polyurea)
chemical coating that fully complies with environmental protection standards.
The front of the box features a 2mm thick perforated protective steel mesh; inside, it is lined with multiple
layers of waterproof and sound-permeable materials, providing strong resistance to wear, as well as waterproof and moisture-proof properties.
The top of the box is designed with a limited groove, and the bottom is equipped with elongated protruding
foot pads to prevent displacement when multiple boxes are stacked.
Product technical specifications
Frequency response | 30Hz-320Hz（-10dB） | Input Connection | 2x Neutrik NLT4M（+1/-1） |
Nominal Sensitivity ity（1W/1m） | 105dB | Dimension(mm) | H/W/D（585/1164/938）mm |
Maximum Peak SPL | 138dB/144dB（Peak） | Weight | 97KG |
Power Handing(AES/Peak) | LF：2000W（Rated）/8000W（Peak） | Case Material | First grade multi-layer plywood |
Driver Components | 2×18”Driver | Surface Treatment | PCP |
Nominal lmpedance | 4Ω | Protection rating | IP54 |
